Product Details
- Size: 13.1
- Place of Origin: China
- Brand Name: XB
- Model Number: SFJP15A
- Weight: 7000.000 kg
This machine mainly used for grinding and polishing of large-diameter optical glass, quartz and crystals, perfect on flat, spherical or aspheric surface. The operating platform can be turned over 90 degrees stably and smoothly, to make the workpiece perfectly meet the level detection requirements.
- Size: 13.1
- Place of Origin: China
- Brand Name: XB
- Model Number: SFJP15A
- Weight: 7000.000 kg
| Main technical specification | ||||
| Worktable dia. | Φ 1500mm | Processing range | Φ300 - Φ1300mm | |
| Worktable speed | 0.5 ~ 16r/min | Swing amplitude | (Swing plate) max adjustable range 250mm (Swing rod) shrinkage range ±150mm Swing times 0~15times/min | |
| Eccentric disc dia. | Φ 590mm | Workable turnover | 90° (power-driven, manual) | |
| Operation mode | PLC control, touch screen | Powder | 10KW / 380V | |
| Size (mm) | 2600 x 2400 x 2100 | Weight (Kg) | 7000 | |
| We also can design and manufacture the machine according to the customer's special requirements | ||||
